garden light garden lamp
Model No: YAUB-03B

80W Led Urban light YAUB-03B

Quantity :
Contact Now
Subscribe to our Newsletter
80W Garden Lamp Garden Light Led Urban YAUB-03B
Product Description
  • The garden lamp garden light is a high efficiency and price competitive garden light which could be used as a wide range of pole top, bracket and suspension applications
  • Compliance with international standards  ENEC, CB, CE, EMC, LM79, Rohs …
  • Garden lamp garden light provides a power output from 30 watt to 120 watt and various lighitng distribution available.

Features
  • Elegant and exquisite appearance design
  • Safe and reliable structural design
  • Simple structural design

Installing Way

  • YAUB-03B garden lamp garden light can be Horizontal only.


Material
  • YAUB-03B garden lamp garden light uses Die casting Aluminum body, Ultra clear tempered galss and PC lens.

Specifications
ModelYAUB-03B-80
Input Wattage (W)30/40/50/60/80
Installation Pipe Diameter φ76mm
Installation Height (m)4 - 8
Input Voltage90~305Vac
Frequency Range50/60Hz
Power Factor≥0.9
Light source LED
DriverInventronics
Meanwell (optional)
other brand of driver（upon request）
Luminaire efficacy (lm/W)130-150
Color Temperature4000K (3000K/5000K、5700K upon request）
Color rendering index≥70
The environment temperature-40～45℃
Humidity of Working Condition20%～90%RH
Protectin GradeIP66
Protection levelIK08
Standards & CertificationsCE
Rohs
MaterialsHousing: ADC12 die-cast aluminum
Cover: Toughened Glass
External Screws: 304 stainless screws
Spray ColorGrey/Black ( other upon request)

Product size and weight
ModelProduct size (mm)Packing size (mm)G.WN.W
LWHLWH(kgs)(kgs)
YAUB-03B-8058145072056052030066.5

Note:
YAUB-03B garden lamp garden light product net weight and gross weight are different due to different product configuration.
The YAUB-03B garden lamp garden light data provided in the table are for reference only, subject to the actual situation.
